Portable toxic and harmful gas detector can be used in: rapid detection of a variety of gas concentration and measurement of environmental temperature and humidity, if the measurement exceeded the limit value, the alarm will emit sound & light vibration as alarm. adopted 2.31-inch high-definition color screen for real-time display, adopted the gas sensors of industrially well-known brands, and the main detection principles include: electrochemical, infrared, catalytic combustion, thermal conductivity, PID photoionization, and so on. Advanced electric circuit design, mature kernel algorithm processing, unique external appearance design, had achieved a number of patents about the software works, external appearance, and so on. is suitable for detecting the concentrations of gases in the atmosphere environment in the pipeline or confined space; and the purity of the gas leakage and various high concentration single gases with the background gas as nitrogen gas or oxygen gas. The types of gases for detection are more than 500 types.
Model Click to consult
|
? 1 ~ 4 kinds of gas can be detected at the same time (in kind), and the unit can be switched freely |
? 3000mA high capacity rechargeable polymer battery is adopted, so it is possible to work for a long period of time. |
|
? You can set whether to display the maximum value, minimum value, and average value |
? Supports real-time detection or timed detection |
|
? Rich man-machine interface |
? English and Chinese interface is optional |
|
? Large-capacity data storage (Larger capacity can be customized), supporting multiple storage modes |
? A variety of alarm methods, when the alarm multi-directional three-dimensional indication alarm state |
|
? Three display modes can be switched |
? Protection grade up to IP65, waterproof splash, dustproof, explosion-proof, anti-vibration |
|
? Graphical display, in the form of a curve to reflect the change trend of gas concentration in a period of time |
? Multiple alarm mode Settings: low alarm, high alarm, interval alarm, TWA/STEL alarm |
|
? Data recovery function, in case of misoperation can select partial or full recovery |
? Standard USB charging interface, with charging protection function, support USB hot swap, charging state instrument can work normally |
|
? Meet the design requirements of intrinsic safety circuit, anti-static, anti-electromagnetic radiation interference |
|
Gases to be detected
Arbitrary combination of 1 ~ 4 types of gases such as toxic gases, oxygen gas, carbon dioxide, inflammable and explosive gases, TVOC, and so on.
Optional configuration: temperature and humidity measurements.
Application scenarios
All the cases which requires the portable rapid detection of gas concentrations such as petroleum, chemical, pharmaceutical, environmental protection, combustion gas distribution, warehousing, smoke gas analysis, air governance, and so on.
Detection range
0 ~ 1, 10, 100, 1000, 5000, 50000, 100000ppm, 200 mg/l, 100%LEL, 20%, 50%, 100%Vol can be selected; and other ranges can be customized.
Resolution
0.01ppm or 0.001ppm (0 ~ 10 ppm);
0.01ppm (0 ~ 100 ppm),
0.1ppm (0 ~ 1000 ppm),
1ppm (0 ~ 1000 ppm or more),
0.01 mg/l (0 ~ 200% mg/l),
0.1% LEL,
0.01%Vol,
0.001% Vol
Detection principle
Electrochemical, catalytic combustion, infrared, thermal conductivity, PID photoionization, and so on, depending on the type of gas, range, field environment and user demand.
Sensor service life
Electrochemical principle: 2 ~ 3 years; Oxygen gas: 2 years or 6 years can be selected; infrared principle: 5 ~ 10 years; catalytic combustion: 3 years; thermal conductivity: 5 years; PID photoionization: 2 ~ 3 years.
Maximum allowable error
≤±3% F.S (higher precision levels can be customized)
Linearity
≤±2%
Linearity
≤±2%
Linearity
≤±2%
Response time
T90≤30 seconds
Recovery time
≤30 seconds
Working environment
Temperature: -40 ℃ ~ + 70 ℃, humidity: ≤10 ~ 95% RH
Sample gas temperature
-40 ℃ ~ + 70 ℃, and the optional configuration of high-temperature sampling and cooling filter handle will be possible to detect the smoke gas at the temperature of 400 ℃ or higher.
Temperature and humidity measurement
Optional configuration: temperature at -40 ℃ ~ + 70 ℃, accuracy level at 0.5 ℃; humidity at 0 ~ 100% RH, precision level at 3 % RH
Power supply
3.7VDC、2100mAh high capacity rechargeable polymer battery
Display mode
2.31-inch high-definition color screen
Detection mode
Diffusion type measurement. The calibrated flow rate is 500 ml/minute.
Alarm mode
It is possible to set as sound & light alarm, vibration alarm, sound & light + vibration alarm, turning off the alarm.
Communication interface
USB (charging and communication), optional: RS485 communication interface
Data storage
Standard configuration is the data storage capacity for 100, 000 entries
Protection level
IP65
Explosion-proof type
Intrinsically safe type
Explosion-proof mark
Exia IIC T4 Ga
Exterior dimensions
130×68×34mm (L×W×H)
Weight
200 g
Standard accessories
Manual, qualification certificate, warranty card, USB charger (including the data cable), belt clip, colorful packaging box (optional high-grade aluminum instrument case)
Optional items
Temperature and humidity measurement function, external gas sampling pump, 1.2 m retractable sampling handle (1-10 meter hose, and the standard length is 1 meter), 0.4 meter stainless steel sampling handle (with dust filter, not retractable)
